262-PLS20003-12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
PLS ROHS3Compliant 2016 Closed Frame PGA, ZIF (ZIP) Socket UL94V-0 125C 1A 30.0muin 0.76mum
PDF
/
Buying Options
Total Price: USD $313.8
Unit Price: USD $313.797542
≥1 USD $313.797542
≥200 USD $125.207334
≥500 USD $121.024435
≥1000 USD $118.956617
Inventory: 5824
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyphenylene Sulfide (PPS)
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper
Technical
Operating Temperature -65°C~125°C
Packaging Bulk
Published 2016
Series PLS
Feature Closed Frame
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type PGA, ZIF (ZIP)
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Contact Finish - Mating Gold
Current Rating (Amps) 1A
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Contact Finish - Post Tin
Lead Length 3.175mm
Termination Post Length 0.125 3.18mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
