26-1508-31

Aries Electronics
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description IC & Component Sockets DUAL ROW COLLET WIRE WRAP 26 PINS
PDF
/
Inventory: 5300
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Number of Pins 26
Housing Material Polyamide (PA46), Nylon 4/6
Number of Positions or Pins (Grid) 26 (2 x 13)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series 508
JESD-609 Code e4
Feature Closed Frame
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
ECCN Code EAR99
Type DIP, 0.2 (5.08mm) Row Spacing
Number of Rows 2
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 1.3 inch
Lead Pitch 2.54mm
Number of Contacts 26
PCB Contact Pattern RECTANGULAR
Lead Length 12.7mm
Body Depth 0.193 inch
Contact Style RND PIN-SKT
Mating Contact Pitch 0.1 inch
PCB Contact Row Spacing 0.1 mm
Termination Post Length 0.500 12.70mm
Pitch - Post 0.100 2.54mm

Dimensions

Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 10.0μin 0.25μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
