256-PRS16001-12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
Transistor Socket
PDF
/
Buying Options
Total Price: USD $306.21
Unit Price: USD $306.206354
≥1 USD $306.206354
≥200 USD $122.178474
≥500 USD $118.095355
≥1000 USD $116.078741
Inventory: 1411
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Lead Free Lead Free
Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Technical
Contact Configuration 16X16
Pitch - Post 0.100 2.54mm
Termination Post Length 0.125 3.18mm
PCB Contact Row Spacing 0.1 mm
Mating Contact Pitch 0.1 inch
Contact Style RND PIN-SKT
Body Depth 0.265 inch
Lead Length 3.175mm
Body Breadth 2.075 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number of Contacts 256
Body Length or Diameter 2.294 inch
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Terminal Pitch 2.54mm
Contact Finish - Mating Gold
Number of Positions 256
Type PGA, ZIF (ZIP)
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed Frame
JESD-609 Code e3
Series PRS
Published 2006
Packaging Bulk
Operating Temperature -65°C~125°C
Physical
Contact Material - Post Beryllium Copper
Contact Material - Mating Beryllium Copper
Housing Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
