24-C212-30
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
EJECT-A-DIP? ROHS3Compliant 2006 RECTANGULAR DIP, 0.6 (15.24mm) Row Spacing Socket UL94V-0 -55C~105C 3A 1000VAC V
PDF
/
Inventory: 3883
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.040 1.02mm
PCB Contact Row Spacing 0.6 mm
Dielectric Withstanding Voltage 1000VAC V
Mating Contact Pitch 0.1 inch
Insulation Resistance 1000000000Ohm
Contact Style RND PIN-SKT
Lead Length 1.016mm
Body Breadth 0.7 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number of Contacts 24
Lead Pitch 2.54mm
Body Length or Diameter 1.49 inch
Pitch - Mating 0.100 2.54mm
Current Rating 3A
Contact Finish - Mating Gold
Additional Feature LATCHED, UL 94V-0
Number of Rows 2
Type DIP, 0.6 (15.24mm) Row Spacing
ECCN Code EAR99
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed Frame
JESD-609 Code e3
Series EJECT-A-DIP?
Published 2006
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 24 (2 x 12)
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Pins 24
Mounting Type Through Hole
Mount Surface Mount
Supply Chain
Factory Lead Time 5 Weeks
