24-4518-10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
CONN IC DIP SOCKET 24POS GOLD
PDF
/
Buying Options
Total Price: USD $3.18
Unit Price: USD $3.178403
≥1 USD $3.178403
≥10 USD $2.998493
≥100 USD $2.82876
≥500 USD $2.668648
≥1000 USD $2.517591
Inventory: 2406
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Width 12.7mm
Length 30.1mm
Height 2.41mm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.125 3.18mm
Mating Contact Pitch 0.1 inch
Row Spacing 10.16 mm
Contact Style RND PIN-SKT
Body Depth 0.165 inch
Body Breadth 0.5 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number of Contacts 24
Lead Pitch 2.54mm
Pitch - Mating 0.100 2.54mm
Current Rating (Amps) 3A
Contact Finish - Mating Gold
Additional Feature STANDARD: UL 94V-0
Number of Rows 2
Number of Positions 24
Type DIP, 0.4 (10.16mm) Row Spacing
Connector Type DIP
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Open Frame
JESD-609 Code e3
Series 518
Published 2007
Packaging Bulk
Physical
Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 24 (2 x 12)
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
