24-3503-31
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets LO-PRO FILE COLLET WIRE WRAP 24 PINS
PDF
/
Inventory: 4478
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 24 (2 x 12)
Contact Material - Mating Beryllium Copper
Contact Material - Post Phosphor Bronze
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series 503
Feature Closed Frame
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
ECCN Code EAR99
Type DIP, 0.3 (7.62mm) Row Spacing
Number of Positions 24
Number of Rows 2
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Lead Pitch 2.54mm
Number of Contacts 24
Lead Length 12.7mm
Termination Post Length 0.500 12.70mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 10.0μin 0.25μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
