24-0513-10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets PIN LINE COLLET SCKT SOLDER TAIL 24 PINS
PDF
/
Buying Options
Total Price: USD $7.23
Unit Price: USD $7.226202
≥1 USD $7.226202
≥200 USD $2.884441
≥500 USD $2.787287
≥1000 USD $2.740022
Inventory: 2483
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 24 (1 x 24)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass
Technical
Packaging Bulk
Published 2006
Series 0513
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type SIP
Number of Positions 24
Number of Rows 1
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 2.4 inch
Lead Pitch 2.54mm
Number of Contacts 24
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Lead Length 3.175mm
Contact Style RND PIN-SKT
Termination Post Length 0.125 3.18mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
