22-4501-30
RoHS
/
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
STANDARD: UL 94V-0 Transistor Socket
PDF
/
Inventory: 2471
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 1.15 inch
Number of Contacts 22
PCB Contact Pattern RECTANGULAR
Body Breadth 0.49 inch
Lead Length 17.526mm
Body Depth 0.3 inch
Contact Style SQ PIN-SKT
Mating Contact Pitch 0.1 inch
PCB Contact Row Spacing 0.4 mm
Termination Post Length 0.690 17.52mm
Pitch - Post 0.100 2.54mm
Current Rating 1.5A
Terminal Pitch 2.54mm
Contact Finish - Mating Tin
Additional Feature STANDARD: UL 94V-0
Type DIP, 0.4 (10.16mm) Row Spacing
ECCN Code EAR99
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Closed Frame
JESD-609 Code e3
Series 501
Packaging Bulk
Operating Temperature -55°C~125°C
Dimensions
Contact Finish Thickness - Mating 200.0μin 5.08μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Physical
Contact Material - Post Phosphor Bronze
Contact Material - Mating Phosphor Bronze
Number of Positions or Pins (Grid) 22 (2 x 11)
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Pins 22
Mounting Type Through Hole
Mount Through Hole
