209-PGM17046-11
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
PGM ROHS3Compliant 2009 Gold PGA Socket UL94V-0 125C 3A 10.0muin 0.25mum
PDF
/
Buying Options
Total Price: USD $1054.02
Unit Price: USD $1054.017126
≥1 USD $1054.017126
≥200 USD $420.559944
≥500 USD $406.506663
≥1000 USD $399.562734
Inventory: 6816
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 10.0μin 0.25μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.165 4.19mm
Lead Length 4.191mm
Contact Finish - Post Gold
Pitch - Mating 0.100 2.54mm
Current Rating 3A
Current Rating (Amps) 3A
Contact Finish - Mating Gold
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type PGA
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series PGM
Published 2009
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 6 Weeks
