18-822-90T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
Vertisockets? 800 ROHS3Compliant 2006 RECTANGULAR DIP, 0.3 (7.62mm) Row Spacing Socket UL94V-0 -55C~105C 1.5A 0.4inch
PDF
/
Inventory: 6941
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Horizontal, Through Hole
Mounting Type Through Hole, Right Angle, Horizontal
Housing Material Polyamide (PA46), Nylon 4/6
Number of Positions or Pins (Grid) 18 (2 x 9)
Contact Material - Mating Phosphor Bronze
Contact Material - Post Phosphor Bronze
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2006
Series Vertisockets? 800
JESD-609 Code e3
Feature Closed Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, 0.3 (7.62mm) Row Spacing
Number of Positions 18
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Tin
Terminal Pitch 2.54mm
Current Rating 1.5A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 0.95 inch
Number of Contacts 18
PCB Contact Pattern RECTANGULAR
Body Breadth 0.4 inch
Lead Length 3.683mm
Body Depth 0.58 inch
Contact Style SQ PIN-SKT
Mating Contact Pitch 0.1 inch
PCB Contact Row Spacing 0.2 mm
Termination Post Length 0.145 3.68mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 200.0μin 5.08μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
