14-C195-10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets LOCK/EJECT DIP SCKT SOLDER TAIL 14 PINS
PDF
/
Inventory: 6339
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 14
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 14 (2 x 7)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2007
Series EJECT-A-DIP?
JESD-609 Code e3
Feature Closed Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, 0.3 (7.62mm) Row Spacing
Number of Rows 2
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 0.95 inch
Lead Pitch 2.54mm
Number of Contacts 14
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Body Breadth 0.4 inch
Lead Length 3.175mm
Contact Style RND PIN-SKT
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.1 inch
Dielectric Withstanding Voltage 1000VAC V
PCB Contact Row Spacing 0.3 mm
Termination Post Length 0.125 3.18mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
