14-81250-10WR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
8 ROHS3Compliant 2007 RECTANGULAR DIP, 0.3 (7.62mm) Row Spacing Socket UL94V-0 -55C~105C 1A 0.395inch
PDF
/
Inventory: 5185
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 200.0μin 5.08μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.140 3.56mm
PCB Contact Row Spacing 0.3 mm
Mating Contact Pitch 0.1 inch
Contact Style SQ PIN-SKT
Body Depth 1.25 inch
Lead Length 3.556mm
Body Breadth 0.395 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 14
Body Length or Diameter 0.75 inch
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Terminal Pitch 2.54mm
Contact Finish - Mating Tin
Additional Feature STANDARD: UL 94V-0
Number of Positions 14
Type DIP, 0.3 (7.62mm) Row Spacing
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed Frame, Elevated
JESD-609 Code e3
Series 8
Published 2007
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Contact Material - Post Phosphor Bronze
Contact Material - Mating Phosphor Bronze
Number of Positions or Pins (Grid) 14 (2 x 7)
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 7 Weeks
