132-PLS14016-12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
PLS ROHS3Compliant 2006 Closed Frame PGA, ZIF (ZIP) Socket UL94V-0 125C 1A 30.0muin 0.76mum
PDF
/
Buying Options
Total Price: USD $211.04
Unit Price: USD $211.038172
≥1 USD $211.038172
≥200 USD $84.205467
≥500 USD $81.391923
≥1000 USD $80.001562
Inventory: 4993
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.125 3.18mm
Lead Length 3.175mm
Contact Finish - Post Tin
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Current Rating (Amps) 1A
Contact Finish - Mating Gold
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Number of Positions 132
Type PGA, ZIF (ZIP)
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed Frame
Series PLS
Published 2006
Packaging Bulk
Operating Temperature -65°C~125°C
Physical
Contact Material - Post Beryllium Copper
Contact Material - Mating Beryllium Copper
Housing Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 5 Weeks
