13-0513-11H
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets PIN LINE COLLET SCKT SOLDER TAIL 13 PINS
PDF
/
Inventory: 7483
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 10.0μin 0.25μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.125 3.18mm
Contact Style RND PIN-SKT
Lead Length 3.175mm
PCB Contact Pattern RECTANGULAR
Number of Contacts 13
Lead Pitch 2.54mm
Pitch - Mating 0.100 2.54mm
Current Rating 3A
Contact Finish - Mating Gold
Additional Feature STANDARD: UL 94V-0
Number of Rows 1
Number of Positions 13
Type SIP
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 0513
Published 2006
Packaging Bulk
Physical
Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 13 (1 x 13)
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
