1109681-624
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets MIRROR IMAGE COLLET 24 PINS
PDF
/
Inventory: 3300
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mounting Type Through Hole
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 24 (2 x 12)
Contact Material - Mating Brass
Technical
Packaging Bulk
Published 2012
JESD-609 Code e4
Feature Spacer
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, 0.6 (15.24mm) Row Spacing
Number of Positions 24
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Current Rating (Amps) 3A
Pitch - Mating 0.100 2.54mm
Number of Contacts 24
Contact Finish - Post Tin-Lead
Termination Post Length 0.125 3.18mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
