10-810-90C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
CONN IC DIP SOCKET 10POS GOLD
PDF
/
Buying Options
Total Price: USD $9.86
Unit Price: USD $9.856
≥1 USD $9.856
≥10 USD $8.73488
≥100 USD $7.615256
≥500 USD $5.957802
Inventory: 196
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Width 9.91mm
Length 13.8mm
Height 26.7mm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.140 3.56mm
Row Spacing 7.62 mm
Contact Finish - Post Tin
Number of Contacts 10
Lead Pitch 2.54mm
Pitch - Mating 0.100 2.54mm
Current Rating (Amps) 3A
Contact Finish - Mating Gold
Additional Feature STANDARD: UL 94V-0
Number of Rows 2
Number of Positions 10
Type DIP, 0.3 (7.62mm) Row Spacing
Connector Type DIP
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed Frame
Series Vertisockets? 800
Published 2007
Packaging Bulk
Physical
Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 10 (2 x 5)
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Through Hole, Right Angle, Vertical
Mount Through Hole, Vertical
Contact Material Copper
Supply Chain
Factory Lead Time 6 Weeks
