08-3503-20
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
STANDARD: UL 94V-0 ICs Socket
PDF
/
Inventory: 8421
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.360 9.14mm
Lead Length 9.144mm
Contact Finish - Post Tin
Number of Contacts 8
Pitch - Mating 0.100 2.54mm
Current Rating 3A
Contact Finish - Mating Gold
Additional Feature STANDARD: UL 94V-0
Type DIP, 0.3 (7.62mm) Row Spacing
ECCN Code EAR99
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed Frame
JESD-609 Code e3
Series 503
Published 2013
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Contact Material - Post Phosphor Bronze
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 8 (2 x 4)
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Pins 8
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
