01-0513-10H
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
0513 ROHS3Compliant 2006 Gold SIP Socket UL94V-0 3A 10.0muin 0.25mum
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.765421
≥1 USD $0.765421
≥200 USD $0.305906
≥500 USD $0.295403
≥1000 USD $0.290151
Inventory: 1893
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Termination Post Length 0.125 3.18mm
Lead Length 3.175mm
Contact Finish - Post Tin
Number of Contacts 1
Lead Pitch 2.54mm
Current Rating 3A
Pitch 2.54mm
Contact Finish - Mating Gold
Additional Feature STANDARD: UL 94V-0
Number of Rows 1
Type SIP
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 0513
Published 2006
Packaging Bulk
Physical
Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 1 (1 x 1)
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
