24-354000-10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors - Adapters
Description
IC & Component Sockets 24P DIP TO SOIC ADAPTER SHORT PIN
PDF
/
Inventory: 8033
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 10.0μin 0.25μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Convert To (Adapter End) SOIC
Convert From (Adapter End) DIP, 0.3 (7.62mm) Row Spacing
Pitch - Post 0.050 1.27mm
Device Socket Type IC SOCKET
Row Spacing 7.62 mm
Number of Contacts 24
Pitch - Mating 0.100 2.54mm
Current Rating 3A
Contact Finish - Mating Gold
Additional Feature STANDARD: UL 94V-0
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Correct-A-Chip? 354000
Published 2006
Physical
Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Pins 24
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold, Tin
Supply Chain
Factory Lead Time 5 Weeks
