232-1285-19-0602J
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors - Adapters
Description
RECEPTACLE DIP SOCKET 32POS .6"
PDF
/
Buying Options
Total Price: USD $23.27
Unit Price: USD $23.2672
≥1 USD $23.2672
≥10 USD $20.37376
≥100 USD $19.49347
≥500 USD $18.86456
≥1000 USD $18.235712
≥3000 USD $17.22959
Inventory: 26
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper
Contact Plating Gold
Mount Wire
Mounting Type Through Hole
Number of Pins 32
Housing Material Polysulfone (PSU), Glass Filled
Weight 453.59237g
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper
Technical
Operating Temperature -55°C~125°C
Published 2011
Series Textool?
Feature Closed Frame
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
Number of Positions 32
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Gender Female
Contact Finish - Mating Gold
Current Rating (Amps) 1A
Pitch 2.54mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Number of Contacts 32
Contact Finish - Post Gold
Insulation Resistance 1GOhm
Termination Post Length 0.620 15.75mm
Pitch - Post 0.100 2.54mm
Convert From (Adapter End) DIP, 0.6 (15.24mm) Row Spacing
Convert To (Adapter End) DIP, 0.6 (15.24mm) Row Spacing
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Contact Finish Thickness - Post 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
