100-016-050

3M
RoHS
/
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description ICs Socket
PDF
/
Inventory: 1331
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type DIP, 0.3 (7.62mm) Row Spacing
Contact Finish - Mating Gold
Current Rating (Amps) 1A
Pitch 2.54mm
Pitch - Mating 0.100 2.54mm
Contact Finish - Post Gold
Termination Post Length 0.126 3.20mm
Pitch - Post 0.100 2.54mm
Feature Open Frame
Series 100
Published 2008
Packaging Bulk
Operating Temperature -65°C~125°C

Dimensions

Contact Finish Thickness - Mating 8.00μin 0.203μm
Contact Finish Thickness - Post Flash

Compliance

Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Physical

Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 16 (2 x 8)
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Number of Pins 16
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
