D459-R1ML-G2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACTION SPDT 16A 250V
PDF
/
Inventory: 5212
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mounting Type Chassis Mount
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2012
Series D4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 16A AC
Termination Style Quick Connect - 0.187 (4.7mm)
Voltage - Rated AC 250V
Actuator Type Lever, Straight
Circuit SPDT
Switch Function On-Mom
Electrical Life 50,000 Cycles
Contact Current Rating 16A
Operating Force 13gf
Overtravel 0.312 (7.9mm)
Differential Travel 0.098 (2.5mm)
Pretravel 0.500 (12.7mm)
Operating Position 0.600 (15.2mm)
Release Force 3.059gf
Compliance
RoHS Status ROHS3 Compliant
