SS-10-2D2 image
Favorite
SS-10-2D2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Switches / Snap Action, Limit Switches
Description Round (Pin Plunger) SS 0.005 (0.12mm) Through Hole Right Angle Snap Switch 0.330 (8.4mm) 4A 250V 25gf
PDF
/
Inventory: 8852
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings IP40
RoHS Status RoHS Compliant

Technical

Release Force 25gf
Operating Position 0.330 (8.4mm)
Pretravel 0.024 (0.6mm)
Differential Travel 0.005 (0.12mm)
Overtravel 0.015 (0.4mm)
Operating Force 150gf
Mechanical Life 10,000,000 Cycles
Max Voltage Rating (DC) 14V
Throw Configuration SPST
Electrical Life 50,000 Cycles
Max Voltage Rating (AC) 250V
Switch Function On-Mom
Circuit SPST-NC
Actuator Type Round (Pin Plunger)
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 4A
Ingress Protection IP40
Orientation Right Angle
Current Rating (Amps) 10A AC
Voltage - Rated DC 30V
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SS
Published 2004
Packaging Bulk
Operating Temperature -25°C~85°C

Physical

Weight 1.6g
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Silver

Supply Chain

Factory Lead Time 18 Weeks
