D2SW-3M
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACTION SPDT 3A 125V
PDF
/
Buying Options
Total Price: USD $10.13
Unit Price: USD $10.1288
≥1 USD $10.1288
≥10 USD $7.85752
≥100 USD $6.41014
≥500 USD $5.583046
Inventory: 211
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 6.4mm
Length 21.2mm
Technical
Release Force 30gf
Operating Position 0.330 (8.4mm)
Pretravel 0.024 (0.6mm)
Differential Travel 0.004 (0.1mm)
Overtravel 0.020 (0.5mm)
Operating Force 180gf
Contact Current Rating 3A
Mechanical Life 5,000,000 Cycles
Max Voltage Rating (DC) 30V
Electrical Life 200,000 Cycles
Max Current Rating 3A
Max Voltage Rating (AC) 250V
Insulation Resistance 100MOhm
Switch Function On-Mom
Circuit SPDT
Actuator Type Round (Pin Plunger)
Voltage - Rated AC 125V
Termination Style Wire Leads
Current Rating 3A
Depth 6.4mm
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation Straight
Current Rating (Amps) 3A AC/DC
Voltage - Rated DC 30V
ECCN Code EAR99
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series D2SW
Published 1998
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Weight 10g
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw, Wire
Contact Material Silver
Supply Chain
Factory Lead Time 11 Weeks
