D2MC-5F1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACTION SPDT 5A 125V
PDF
/
Buying Options
Total Price: USD $13.85
Unit Price: USD $13.849252
≥1 USD $13.849252
≥10 USD $13.065332
≥100 USD $12.325787
≥500 USD $11.628101
≥1000 USD $10.969907
Inventory: 1971
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Technical
Operating Temperature -25°C~80°C
Packaging Bulk
Published 2010
Series D2MC
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Quick Connect
Max Operating Temperature 80°C
Min Operating Temperature -25°C
Current Rating (Amps) 5A AC
Ingress Protection IP40
Current Rating 5A
Termination Style Quick Connect - 0.205 (5.2mm)
Voltage - Rated AC 125V
Actuator Type Without
Circuit SPDT
Switch Function On-Mom
Electrical Life 100,000 Cycles
Throw Configuration SPDT
Mechanical Life 10,000,000 Cycles
Operating Force 0.076gfm
Overtravel 17°
Differential Travel 3°
Pretravel 21°
Release Force 0.009gfm
Compliance
RoHS Status RoHS Compliant
Ratings IP40
