D2HW-BL273MR
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Snap Action, Limit Switches
Description
Lever Simulated Roller D2HW 0.020 (0.5mm) Chassis Mount Snap Switch 2mm 2A 125V 2A@12VDC
PDF
/
Buying Options
Total Price: USD $7.52
Unit Price: USD $7.521921
≥1 USD $7.521921
≥10 USD $7.096154
≥100 USD $6.694479
≥500 USD $6.315553
≥1000 USD $5.958071
Inventory: 1192
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Body Height 6.5mm
Technical
Actuator Travel 2 mm
Release Force 20gf
Operating Position 0.425 (10.8mm)
Differential Travel 0.020 (0.5mm)
Overtravel 0.079 (2.0mm)
Contact (DC) Max Rating R Load 2A@12VDC
Operating Force 183gf
Contact Current Rating 2A
Switch Type SNAP ACTING/LIMIT SWITCH
Mechanical Life 1,000,000 Cycles
Max Voltage Rating (DC) 42V
Throw Configuration SPST
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 125V
Contact Current(DC)-Max 2A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Lever, Simulated Roller
Body Breadth 5.3 mm
Body Length or Diameter 13.3mm
Voltage - Rated AC 125V
Termination Style Wire Leads
Current Rating 2A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation Straight
Current Rating (Amps) 100mA AC 2A DC
Voltage - Rated DC 12V
HTS Code 8536.50.70.00
ECCN Code EAR99
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Support Posts
Series D2HW
Published 2004
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Package / Case 125
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw, Wire
Contact Material Gold
Supply Chain
Factory Lead Time 20 Weeks
