RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACTION SPDT 6A 120V
PDF
/
Inventory: 2791
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Housing Material Zinc
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Published 2008
Series GLS
Feature Steel Roller
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Conduit
ECCN Code EAR99
Number of Positions 2
HTS Code 8536.50.70.00
Voltage - Rated DC 125V
Current Rating (Amps) 6A AC 550mA DC
Orientation Right Angle
Ingress Protection IP67 - Dust Tight, Waterproof
Depth 82mm
Current Rating 10A
Termination Style Screw Terminal
Voltage - Rated AC 120V
Actuator Type Side Rotary, Adjustable Roller
Circuit SPDT
Switch Function On-Mom
Contact Current(DC)-Max 0.55A
Max Voltage Rating (AC) 600V
Max Current Rating 6A
Number of Poles 1
Max Voltage Rating (DC) 250V
Mechanical Life 15,000,000 Cycles
Switch Type SNAP ACTING/LIMIT SWITCH
Operating Force 33gfm
Contact Current(AC)-Max 6A
Overtravel 59°
Differential Travel 12°
Pretravel 26°
Dimensions
Length 42mm
Width 42mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
