1SE3-3
RoHS
/
Package /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACT SPST-NO 5A 250V
PDF
/
Buying Options
Total Price: USD $268.21
Unit Price: USD $268.214778
≥1 USD $268.214778
≥10 USD $253.032819
≥100 USD $238.710197
≥500 USD $225.198312
≥1000 USD $212.451231
Inventory: 1097
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Chassis Mount, Panel, Screw, Wire
Weight 28.35g
Actuator Material Steel
Technical
Packaging Bulk
Published 2012
Pbfree Code yes
Termination Wire Leads
ECCN Code EAR99
Max Operating Temperature 105°C
Min Operating Temperature -54°C
HTS Code 8536.50.70.00
Voltage - Rated DC 30V
Orientation Straight
Depth 8.79mm
Current Rating 5A
Voltage - Rated AC 250V
Switch Function Off-Mom
Contact Current(DC)-Max 5A
Sealing CORROSION PROOF; EPOXY TERMINAL SEALED
Max Voltage Rating (AC) 250V
Throw Configuration SPST
Max Voltage Rating (DC) 30V
Switch Type SNAP ACTING/LIMIT SWITCH
Operating Force 4.73 N
Contact Current(AC)-Max 5A
Contact (AC) Max Rating R Load 5A@250VAC
Contact (DC) Max Rating R Load 5A@30VDC
Overtravel 76.2 μm
Differential Travel 101.6 μm
Pretravel 1.27 mm
Operating Position 10.795 mm
Current Rating (Max) 5A
Dimensions
Length 22.25mm
Body Height 15.24mm
Compliance
RoHS Status RoHS Compliant
