MS0850500F080S1A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACTION SPDT 5A 125V
PDF
/
Buying Options
Total Price: USD $1.17
Unit Price: USD $1.1704
≥1 USD $1.1704
≥10 USD $1.1044
≥100 USD $0.773027
≥500 USD $0.684693
≥1000 USD $0.618429
Inventory: 591
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Termination 0.138 inch
Body Height 10.5918mm
Technical
Release Force 25gf
Operating Position 0.335 (8.5mm)
Pretravel 0.043 (1.1mm)
Contact Timing SNAP ACTION
Contact (AC) Max Rating R Load 5A@250VAC
Contact Current(AC)-Max 5A
Operating Force 80gf
Contact Current Rating 5A
Switch Type SNAP ACTING/LIMIT SWITCH
Mechanical Life 1,000,000 Cycles
Electrical Life 50,000 Cycles
Dielectric Withstanding Voltage 1000VAC V
Insulation Resistance 100000000Ohm
Contact Resistance 0.1mOhm
Switch Function On-Mom
Circuit SPDT
Actuator Type Round (Pin Plunger)
Body Breadth 6.4008 mm
Body Length or Diameter 19.812mm
Voltage - Rated AC 250V
Termination Style Solder Lug
Current Rating 5A
Current Rating (Amps) 5A AC
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MS
Published 2008
Packaging Bulk
Operating Temperature -25°C~85°C
Physical
End Contact Plating SILVER
Terminal Material COPPER ALLOY
Actuator Material POLYBUTYLENE TEREPHTHALATE
Housing Material POLYBUTYLENE TEREPHTHALATE
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 11 Weeks
