TMCJH3SP0040Y
RoHS
RoHS compliant
RoHS compliantPackage 124
Category Switches / Snap Action, Limit Switches
Description
Round (Pin Plunger) TM 0.013 (0.33mm) Chassis Mount Snap Switch 10.2mm 5A 250V 60gf
PDF
/
Inventory: 5176
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 37.6mm
Technical
Release Force 60gf
Operating Position 0.579 (14.7mm)
Pretravel 0.055 (1.4mm)
Differential Travel 0.013 (0.33mm)
Overtravel 0.035 (0.9mm)
Operating Force 150gf
Throw Configuration SPST
Electrical Life 150000 cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Round (Pin Plunger)
Voltage - Rated AC 250V
Termination Style Quick Connect - 0.187 (4.7mm)
Current Rating 5A
Depth 10.2mm
Orientation Straight
Current Rating (Amps) 5A AC
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TM
Published 2012
Packaging Bulk
Operating Temperature -55°C~150°C
Physical
Actuator Material Thermoplastic
Housing Material Thermoplastic
Package / Case 124
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
