TMCGD6SA1010C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Basic / Snap Action Switches SPDT 10A SOLDER
PDF
/
Inventory: 8142
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Technical
Operating Temperature -55°C~150°C
Packaging Bulk
Published 2012
Series TM
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Voltage - Rated DC 125V
Current Rating (Amps) 10A AC 500mA DC
Current Rating 10A
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Lever, Roller
Circuit SPDT
Switch Function On-Mom
Max Voltage Rating (AC) 250V
Electrical Life 350,000 Cycles
Max Voltage Rating (DC) 250V
Operating Force 90gf
Overtravel 0.035 (0.9mm)
Differential Travel 0.013 (0.33mm)
Pretravel 0.071 (1.8mm)
Operating Position 0.812 (20.6mm)
Release Force 28gf
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
