TFECK6ST1640W
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Switch Snap Action N.C. SPST Lever Quick Connect 11A 277VAC 250VDC 248.57VA 0.69N Screw Mount
PDF
/
Inventory: 5317
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 72.6mm
Technical
Release Force 10gf
Operating Position 0.600 (15.2mm)
Pretravel 0.250 (6.35mm)
Differential Travel 0.045 (1.1mm)
Overtravel 0.125 (3.2mm)
Operating Force 70gf
Contact Current Rating 11A
Max Voltage Rating (DC) 250V
Throw Configuration SPST
Max Current Rating 11A
Max Voltage Rating (AC) 277V
Switch Function On-Mom
Circuit SPST-NC
Actuator Type Lever, Straight
Voltage - Rated AC 277V
Termination Style Quick Connect - 0.187 (4.7mm)
Current Rating 11A
Depth 10.2mm
Orientation Straight
Current Rating (Amps) 11A AC 500mA DC
Voltage - Rated DC 125V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TF
Published 2012
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Thermoplastic
Housing Material Thermoplastic
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw
Contact Material Silver
Supply Chain
Factory Lead Time 11 Weeks
