TFECJ6VP0040Y
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACT SPST-NO 15A 277V
PDF
/
Buying Options
Total Price: USD $12.17
Unit Price: USD $12.170583
≥1 USD $12.170583
≥200 USD $4.710685
≥500 USD $4.54526
≥1000 USD $4.462547
Inventory: 1353
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Silver
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Housing Material Thermoplastic
Actuator Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2012
Series TF
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated DC 125V
Current Rating (Amps) 15A AC 500mA DC
Depth 10.2mm
Current Rating 15A
Termination Style Quick Connect - 0.187 (4.7mm)
Voltage - Rated AC 277V
Actuator Type Round (Pin Plunger)
Circuit SPST-NO
Switch Function Off-Mom
Max Voltage Rating (AC) 277V
Max Current Rating 15A
Throw Configuration SPST
Max Voltage Rating (DC) 250V
Operating Force 225gf
Overtravel 0.050 (1.27mm)
Differential Travel 0.010 (0.25mm)
Pretravel 0.047 (1.2mm)
Operating Position 0.579 (14.7mm)
Release Force 56gf
Dimensions
Length 38.4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
