TFECJ6ST264AW

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Snap Action, Limit Switches
Description SWITCH SNAP ACT SPST-NC 15A 277V
PDF
/
Buying Options
Total Price: USD $9.17
Unit Price: USD $9.169865
≥1 USD $9.169865
≥10 USD $8.650815
≥100 USD $8.161148
≥500 USD $7.6992
≥1000 USD $7.263391
Inventory: 976
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Contact Material Silver
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Actuator Material Thermoplastic

Technical

Operating Temperature -40°C~85°C
Packaging Bulk
Published 2012
Series TF
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Voltage - Rated DC 125V
Current Rating (Amps) 15A AC 500mA DC
Depth 10.2mm
Current Rating 15A
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 277V
Actuator Type Lever, Straight
Circuit SPST-NC
Switch Function On-Mom
Max Voltage Rating (AC) 277V
Max Current Rating 15A
Throw Configuration SPST
Max Voltage Rating (DC) 250V
Operating Force 36gf
Overtravel 0.235 (6.0mm)
Differential Travel 0.100 (2.54mm)
Pretravel 0.500 (12.7mm)
Operating Position 0.600 (15.2mm)
Release Force 6.000gf

Dimensions

Length 80mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
