TFCJV4VA105AC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Lever Roller TF 0.015 (0.38mm) Chassis Mount Snap Switch 10.2mm 21A 277V 20gf
PDF
/
Inventory: 8888
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 39.9mm
Technical
Release Force 20gf
Operating Position 0.812 (20.6mm)
Pretravel 0.060 (1.5mm)
Differential Travel 0.015 (0.38mm)
Overtravel 0.030 (0.76mm)
Operating Force 180gf
Throw Configuration SPDT
Max Current Rating 21A
Max Voltage Rating (AC) 277V
Switch Function On-Mom
Circuit SPDT
Actuator Type Lever, Roller
Voltage - Rated AC 277V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 21A
Depth 10.2mm
Orientation Straight
Current Rating (Amps) 21A AC
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TF
Published 2012
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Thermoplastic
Housing Material Thermoplastic
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Contact Material Metal
Supply Chain
Factory Lead Time 8 Weeks
