TFCGF5SP004AC

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Snap Action, Limit Switches
Description Basic / Snap Action Switches Snap
PDF
/
Inventory: 1541
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Length 39.9mm

Technical

Release Force 15gf
Operating Position 0.579 (14.7mm)
Pretravel 0.047 (1.2mm)
Differential Travel 0.010 (0.25mm)
Overtravel 0.050 (1.27mm)
Operating Force 75gf
Max Voltage Rating (DC) 30V
Throw Configuration SPDT
Electrical Life 6,000 Cycles
Max Current Rating 1A
Max Voltage Rating (AC) 125V
Switch Function On-Mom
Circuit SPDT
Actuator Type Round (Pin Plunger)
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 1A
Depth 10.2mm
Orientation Straight
Current Rating (Amps) 1A AC/DC
Voltage - Rated DC 30V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TF
Published 2012
Packaging Bulk
Operating Temperature -40°C~85°C

Physical

Actuator Material Thermoplastic
Housing Material Thermoplastic
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Contact Material Gold

Supply Chain

Factory Lead Time 11 Weeks
