TFCGF5SP0040Y
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Switch Snap Action N.O. SPST Pin Plunger Quick Connect 1A 125VAC 30VDC 0.74N Screw Mount
PDF
/
Inventory: 9346
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 38.4mm
Technical
Release Force 15gf
Operating Position 0.579 (14.7mm)
Pretravel 0.047 (1.2mm)
Differential Travel 0.010 (0.25mm)
Overtravel 0.050 (1.27mm)
Operating Force 75gf
Max Voltage Rating (DC) 30V
Throw Configuration SPST
Electrical Life 6,000 Cycles
Max Current Rating 1A
Max Voltage Rating (AC) 125V
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Round (Pin Plunger)
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.187 (4.7mm)
Current Rating 1A
Depth 10.2mm
Orientation Straight
Current Rating (Amps) 1A AC/DC
Voltage - Rated DC 30V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TF
Published 2012
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Thermoplastic
Housing Material Thermoplastic
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Contact Material Gold
Supply Chain
Factory Lead Time 11 Weeks
