TFCFF5ST155AC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Switch Snap Action N.O./N.C. SPDT Lever Quick Connect 1A 125VAC 30VDC 0.29N Screw Mount
PDF
/
Buying Options
Total Price: USD $23.45
Unit Price: USD $23.45102
≥1 USD $23.45102
≥200 USD $9.074765
≥500 USD $8.757043
≥1000 USD $8.599495
Inventory: 6603
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 50.3mm
Technical
Release Force 4.000gf
Operating Position 0.600 (15.2mm)
Pretravel 0.110 (2.8mm)
Differential Travel 0.030 (0.76mm)
Overtravel 0.065 (1.7mm)
Operating Force 30gf
Max Voltage Rating (DC) 30V
Throw Configuration SPDT
Electrical Life 6,000 Cycles
Max Current Rating 1A
Max Voltage Rating (AC) 125V
Switch Function On-Mom
Circuit SPDT
Actuator Type Lever, Straight
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 1A
Depth 10.2mm
Current Rating (Amps) 1A AC/DC
Voltage - Rated DC 30V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TF
Published 2012
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Thermoplastic
Housing Material Thermoplastic
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Contact Material Gold
Supply Chain
Factory Lead Time 11 Weeks
