TFCFF5SA1540C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Lever Roller TF 0.030 (0.76mm) Chassis Mount Snap Switch 10.2mm 1A 125V 4.000gf
PDF
/
Buying Options
Total Price: USD $23.88
Unit Price: USD $23.880338
≥1 USD $23.880338
≥200 USD $9.241503
≥500 USD $8.917217
≥1000 USD $8.757043
Inventory: 1791
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Gold
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Housing Material Thermoplastic
Actuator Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2012
Series TF
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated DC 30V
Current Rating (Amps) 1A AC/DC
Orientation Straight
Depth 10.2mm
Current Rating 1A
Termination Style Quick Connect - 0.187 (4.7mm)
Voltage - Rated AC 125V
Actuator Type Lever, Roller
Circuit SPDT
Switch Function On-Mom
Max Voltage Rating (AC) 125V
Max Current Rating 1A
Electrical Life 6,000 Cycles
Throw Configuration SPDT
Max Voltage Rating (DC) 30V
Operating Force 30gf
Overtravel 0.065 (1.7mm)
Differential Travel 0.030 (0.76mm)
Pretravel 0.100 (2.5mm)
Operating Position 0.812 (20.6mm)
Release Force 4.000gf
Dimensions
Length 49.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
