MMGGD1W2L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Lever Roller MM 0.012 (0.3mm) Through Hole Right Angle Snap Switch 18.49mm 7A 250V 20gf
PDF
/
Buying Options
Total Price: USD $46.53
Unit Price: USD $46.529176
≥1 USD $46.529176
≥200 USD $18.006424
≥500 USD $17.373606
≥1000 USD $17.061136
Inventory: 5034
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Silver
Mount Screw, Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Phenolic
Technical
Operating Temperature -55°C~135°C
Packaging Bulk
Published 2012
Series MM
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 135°C
Min Operating Temperature -55°C
Current Rating (Amps) 7A AC
Orientation Right Angle
Depth 18.49mm
Current Rating 7A
Termination Style PC Pin
Voltage - Rated AC 250V
Actuator Type Lever, Roller
Circuit SPDT
Switch Function On-Mom
Max Voltage Rating (AC) 250V
Max Current Rating 7A
Electrical Life 100,000 Cycles
Throw Configuration SPDT
Max Voltage Rating (DC) 28V
Operating Force 170gf
Overtravel 0.015 (0.4mm)
Differential Travel 0.012 (0.3mm)
Pretravel 0.075 (1.9mm)
Operating Position 0.531 (13.5mm)
Release Force 20gf
Dimensions
Length 18.05mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
