HBS2KCF5ST011C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Switch Snap Action N.O./N.C. SPDT Lever Solder/Screw 1A 125VAC 30VDC Screw Mount
PDF
/
Buying Options
Total Price: USD $39.06
Unit Price: USD $39.062714
≥1 USD $39.062714
≥200 USD $15.116731
≥500 USD $14.586319
≥1000 USD $14.323739
Inventory: 5722
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Gold
Mount Chassis Mount, Screw, Solder
Mounting Type Chassis Mount
Housing Material Phenolic
Technical
Operating Temperature -55°C~150°C
Packaging Bulk
Published 2012
Series HB
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 30V
Current Rating (Amps) 1A AC/DC
Orientation Straight
Ingress Protection IP65 - Dust Tight, Water Resistant
Depth 17.5mm
Current Rating 1A
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Lever, Straight
Circuit SPDT
Switch Function On-Mom
Max Voltage Rating (AC) 125V
Max Current Rating 1A
Throw Configuration SPDT
Max Voltage Rating (DC) 30V
Operating Position 0.720 (18.3mm)
Dimensions
Length 70.62mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP65, Water Resistant
