DS2D6CQ3
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Snap Action, Limit Switches
Description
Pushbutton Switches DPDT 10A 125/250 Vac PullOut Button Q.C.
PDF
/
Buying Options
Total Price: USD $18.47
Unit Price: USD $18.4712
≥1 USD $18.4712
≥10 USD $14.322
≥100 USD $13.568192
≥500 USD $12.814384
≥1000 USD $11.68376
≥3000 USD $10.929987
Inventory: 25
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 17.3mm
Length 39.9mm
Height 26.6mm
Technical
Operating Position 0.660 (16.76mm)
Overtravel 0.520 (13.2mm)
Operating Force 560gf
Mechanical Life 50000 cycles
Electrical Life 50,000 Cycles
Max Voltage Rating (AC) 250V
Switch Function On-Mom
Circuit DPDT
Actuator Type Push-Pull Plunger
Approval Agency CSA, UL
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 10A
Current Rating (Amps) 10A AC
Color White
Number of Positions 3
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Pull On Lock
Series DS
Published 2015
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Housing Material Polyamide
Package / Case 125
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Gold, Silver
Contact Material Silver
Supply Chain
Factory Lead Time 11 Weeks
