ASKHF3L04AY
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Switch Snap Action N.O. SPST Leaf Lever Quick Connect 25A 250VAC 24VDC 1491.4VA 3.33N Screw Mount
PDF
/
Inventory: 4444
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 65.4mm
Technical
Release Force 28gf
Operating Position 0.312 (7.9mm)
Pretravel 0.281 (7.14mm)
Overtravel 0.062 (1.6mm)
Operating Force 340gf
Max Voltage Rating (DC) 24V
Throw Configuration SPST
Electrical Life 75,000 Cycles
Max Current Rating 25A
Max Voltage Rating (AC) 250V
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Lever, Leaf
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 2A
Depth 16.3mm
Current Rating (Amps) 25A AC 2A DC
Voltage - Rated DC 24V
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series A
Published 2012
Packaging Bulk
Operating Temperature -55°C~85°C
Physical
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
