ADPFF3B14AC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACTION DPDT 25A 125V
PDF
/
Inventory: 4281
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 65.4mm
Technical
Release Force 170gf
Pretravel 0.050 (1.27mm)
Overtravel 0.050 (1.27mm)
Operating Force 1134gf
Max Voltage Rating (DC) 24V
Throw Configuration DPDT
Electrical Life 75,000 Cycles
Max Current Rating 25A
Max Voltage Rating (AC) 250V
Switch Function On-Mom
Circuit DPDT
Actuator Type Round (Pin Plunger)
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 2A
Depth 16.3mm
Current Rating (Amps) 25A AC 2A DC
Voltage - Rated DC 24V
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Large Black Button
Series A
Published 2012
Packaging Bulk
Operating Temperature -55°C~85°C
Physical
Actuator Material Phenolic
Mounting Type Panel Mount
Mount Panel, Screw
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
