ADPDC2T04AC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACTION DPDT 15A 125V
PDF
/
Buying Options
Total Price: USD $13.28
Unit Price: USD $13.2792
≥1 USD $13.2792
≥10 USD $10.30128
≥100 USD $9.758848
≥500 USD $9.216768
≥1000 USD $8.403648
≥3000 USD $7.861427
Inventory: 69
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 85.4mm
Technical
Release Force 28gf
Operating Position 0.312 (7.9mm)
Pretravel 0.312 (7.9mm)
Overtravel 0.187 (4.75mm)
Operating Force 170gf
Number of Poles 2
Electrical Life 200,000 Cycles
Max Current Rating 15A
Max Voltage Rating (AC) 250V
Switch Function On-Mom
Circuit DPDT
Actuator Type Lever, Straight
Approval Agency CSA, UL
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 15A
Depth 16.3mm
Orientation Straight
Current Rating (Amps) 15A AC
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series A
Published 2008
Packaging Bulk
Operating Temperature -55°C~85°C
Physical
Housing Material Phenolic
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw
Contact Material Gold, Silver
Supply Chain
Factory Lead Time 14 Weeks
