C56313L2X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE DP3T 500MA 125V
PDF
/
Buying Options
Total Price: USD $13.51
Unit Price: USD $13.508
≥1 USD $13.508
≥10 USD $12.89728
Inventory: 75
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Actuator Material Thermoplastic
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 1998
Series 56300
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
Voltage - Rated DC 125V
Current Rating (Amps) 500mA AC/DC
Orientation Vertical
Current Rating 400mA
Contact Finish Silver
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Standard
Circuit DP3T
Switch Function On-On-On
Throw Configuration DP3T, DPTT
Contact Current Rating 500mA
Illumination Type Non-Illuminated
Contact Timing Non-Shorting (BBM)
Switch Travel 3.81mm
Dimensions
Actuator Length 4.75mm
Compliance
RoHS Status ROHS3 Compliant
