C46206LR
RoHS
/
Package /
Category Switches / Slide Switches
Description
Slide Switches 2POS DPDT PC SWITCH
PDF
/
Inventory: 6738
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Actuator Length 8.74mm
Length - Termination 0.156 inch
Technical
Switch Travel 4.78mm
Actuator Color BLACK
PCB Hole Count 6
Contact Timing Non-Shorting (BBM)
Contact Current(AC)-Max 3A
Contact Current Rating 3A
Max Voltage Rating (DC) 125V
Dielectric Withstanding Voltage 1000VRMS V
Max Voltage Rating (AC) 125V
Contact Current(DC)-Max 0.5A
Insulation Resistance 1000000000Ohm
Contact Style Non-Shorting
Switch Function On-On
Circuit DPDT
Actuator Type Standard
Body Breadth 13.4874 mm
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 3A
Orientation Straight
Current Rating (Amps) 3A AC 500mA DC
Voltage - Rated DC 125V
HTS Code 8536.50.90.50
Additional Feature UL,CSA RIGID PLASTIC BODY
Number of Positions 2
Type General Purpose
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series 46200R
Published 1998
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
End Contact Plating SILVER
Actuator Material Thermoplastic
Housing Material Steel
Number of Pins 2
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
