46206LFR
RoHS
/
Package /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 3A 125V
PDF
/
Inventory: 7764
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Actuator Length Flush
Length - Termination 0.312 inch
Body Height 7.54mm
Technical
Switch Travel 4.78mm
Actuator Color BLACK
Contact (DC) Max Rating R Load .5A@125VDC
Contact Timing Non-Shorting (BBM)
Contact (AC) Max Rating R Load 3A@125VAC
Contact Current(AC)-Max 3A
Switch Type SLIDE SWITCH
Dielectric Withstanding Voltage 1000VRMS V
Contact Current(DC)-Max 0.5A
Insulation Resistance 1000000000Ohm
Contact Style Non-Shorting
Switch Function On-On (Line Voltage Selector)
Circuit DPDT
Actuator Type Screwdriver Slot
Body Breadth 13.49 mm
Body Length or Diameter 22.22mm
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 3A
Current Rating (Amps) 3A AC 500mA DC
Voltage - Rated DC 125V
HTS Code 8536.50.90.50
Additional Feature UL,CSA RIGID PLASTIC BODY
Terminal Finish Silver (Ag)
Number of Positions 2
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature 115V-230V Marking
JESD-609 Code e4
Series 46200R
Published 2005
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
End Contact Plating SILVER
Center Contact Plating SILVER
Actuator Material Thermoplastic
Housing Material STEEL
Mounting Type Panel Mount
Mount Panel
Contact Material Copper Alloy
