CL-SB-23C-12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Standard CL-SB Through Hole Right Angle Bulk Slide Switch 2.00mm 200mA 12V 160/260gf
PDF
/
Buying Options
Total Price: USD $3.38
Unit Price: USD $3.380718
≥1 USD $3.380718
≥200 USD $1.349661
≥500 USD $1.30371
≥1000 USD $1.28139
Inventory: 2394
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 2.00mm
Technical
Switch Travel 2.00mm
Contact Timing Non-Shorting (BBM)
Operating Force 160/260gf
Throw Configuration DP3T
Electrical Life 10,000 Cycles
Contact Style Non-Shorting
Switch Function On-On-On
Circuit DP3T
Actuator Type Standard
Termination Style PC Pin
Contact Finish Gold
Current Rating 200mA
Current Rating (Amps) 200mA DC
Voltage - Rated DC 12V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CL-SB
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Polyamide (PA), Nylon
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold
Contact Material Copper
Supply Chain
Factory Lead Time 11 Weeks
