CL-SB-13A-02
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Standard CL-SB Surface Mount Bulk Slide Switch 2.00mm 200mA 12V 160/260gf
PDF
/
Inventory: 2684
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 2.00mm
Technical
Switch Travel 2.00mm
Contact Timing Non-Shorting (BBM)
Operating Force 160/260gf
Throw Configuration SP3T
Electrical Life 10,000 Cycles
Contact Style Non-Shorting
Switch Function On-On-On
Circuit SP3T
Actuator Type Standard
Termination Style J Lead
Contact Finish Gold
Current Rating 200mA
Current Rating (Amps) 200mA DC
Voltage - Rated DC 12V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CL-SB
Published 2016
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Polyamide (PA), Nylon
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Contact Material Copper
Supply Chain
Factory Lead Time 11 Weeks
